L293D Motor Driver Shield for Arduino Uno
- Ada Fruit Motor Driver Shield
- Motor controller
- 2 connections for 5V ‘hobby’ servos
- Up to 4 bi-directional DC motors with individual 8-bit speed selection
- Up to 2 stepper motors (uni-polar or bi-polar) with single coil, double coil, interleaved or micro-stepping
- 2-pin terminal block to connect external power, for separate logic/motor supplies
- Big terminal block connectors to easily hook up wires (10-22AWG) and power
₹175.00
Compare
The motor shield can drive up to 4 DC motors bi-directionally. That means they can be driven forwards and backwards. The speed can also be varied at 0.5% increments using the high-quality built in PWM. This means the speed is very smooth and won’t vary!. Note that the H-bridge chip is not meant for driving loads over 0.6A or that peak over 1.2A so this is for small motors.
Technical Specifications
- Supply Voltage: 4.5V to 25V
- Rated current: 0.6A per bridge (1.2A peak)
- Dimensions(assembled): 69mm x 53mm x 14.3mm
- Wake up and transmit packets in < 2ms
- Weight: 32g
